SINOMACH NLX854 Technical Specifications
Review the NLX854’s engine, drivetrain, PTO and hydraulic specifications below. Confirm the final configuration with B&F Group before purchase, as optional equipment and supplied specifications may vary.
Engine and Transmission
| Specification | NLX854 |
|---|---|
| Rated Power | 62.5 kW / 85 HP |
| Rated Engine Speed | 2,300 rpm |
| Engine Type | 4-cylinder, naturally aspirated diesel |
| Drive Type | 4×4 |
| Clutch | Independent, dual action |
| Standard Transmission | 12 Forward + 4 Reverse |
| Optional Transmission | 12F+12R or 24F+8R |
| Speed Range | 1.64–26.97 km/h |
| Operating Mass | 3,900 kg |
PTO, Hydraulics and Braking
| Specification | NLX854 |
|---|---|
| Rear PTO Speed | 540 / 1,000 rpm |
| Lifting Force at Link Joint | ≥ 23 kN |
| Hydraulic Output | 1,2 or 3 Sets |
| Brakes | Wet Disc |
Dimensions and Tyres
| Specification | NLX854 |
|---|---|
| Overall Dimensions (L × W × H) | 4,350 × 2,300 × 2,765 mm |
| Wheelbase | 2,314 mm |
| Ground Clearance | 430 mm |
| Front Wheel Track | 1,630–1,960 mm |
| Rear Wheel Track | 1,540–2,120 mm |
| Minimum Turning Radius | 5.6 ± 0.3 m |
| Front Tyres | 12.4-24 |
| Rear Tyres | 18.4-30 |
Need Help Checking Compatibility?
Share your implement specifications and intended application with B&F Group. The team can help you review the relevant tractor specifications before you request a quotation.
Get A Tractor RecommendationWhat Can the NLX854 Be Used For?
- Farm and Plantation Operations
The NLX854 can be considered for farm and plantation work where its power output, dimensions and implement configuration suit the job. Assess the terrain, working space and workload before selecting the tractor. - Field Preparation and Tillage
The 540/1,000 rpm rear PTO provides options for compatible PTO-driven equipment. Confirm the implement’s required PTO speed, power demand, weight and mounting requirements before using it for tillage or other field-preparation work. - Mowing and Vegetation Management
The NLX854 may be suitable for compatible mowers, slashers and grass-management equipment when the power demand, mounting requirements and operating conditions match the supplied tractor. - Spraying and Fertilising
The tractor can be evaluated for compatible sprayers, fertiliser spreaders and other agricultural implements. Check the implement’s mounting, PTO and hydraulic requirements before confirming suitability. - Agricultural and Trailer Transport
The NLX854 can be considered for suitable agricultural transport tasks when paired with compatible equipment. Confirm the towing arrangement, load limits and operating conditions with B&F Group before selecting a trailer or other towing equipment.
